SABIC Innovative Plastics ULTEM 2300 PEI (Asia Pacific)

Seller in Chicago price: $2588 per MT

SABIC Innovative Plastics ULTEM 2300 PEI (Asia Pacific) in Polymer, Thermoplastic, Polyetherimide (PEI)

  • Physical Properties
  • Specific Gravity
  • 1.51 g/cc
  • Water Absorption
  • 0.16 % @Time 86400 sec
  • Moisture Absorption at Equilibrium
  • 0.90 %
  • Linear Mold Shrinkage, Flow
  • 0.0020 - 0.0040 cm/cm @Thickness 3.20 mm
  • Linear Mold Shrinkage, Transverse
  • 0.0020 - 0.0040 cm/cm @Thickness 3.20 mm
  • Melt Flow
  • 5.0 g/10 min @Load 6.60 kg, Temperature 337 °C
  • Mechanical Properties
  • Hardness, Rockwell M
  • 114
  • Tensile Strength at Break
  • 158 MPa
  • Tensile Strength, Yield
  • 168 MPa
  • Elongation at Break
  • 3.0 %
  • Tensile Modulus
  • 9.30 GPa
  • Flexural Strength
  • 227 MPa
  • Flexural Modulus
  • 8.96 GPa
  • Izod Impact, Notched
  • 0.850 J/cm
  • Izod Impact, Notched
  • 4.91 J/cm @Thickness 3.20 mm
  • Izod Impact, Unnotched
  • 4.27 J/cm
  • Thermal Properties
  • CTE, linear, Parallel to Flow
  • 19.8 µm/m-°C @Temperature -20.0 - 150 °C
  • Deflection Temperature at 0.46 MPa (66 psi)
  • 212 °C @Thickness 6.40 mm
  • Deflection Temperature at 1.8 MPa (264 psi)
  • 210 °C @Thickness 6.40 mm
  • Vicat Softening Point
  • 227 °C
  • Glass Transition Temp, Tg
  • 217 °C
  • UL RTI, Electrical
  • 180 °C
  • UL RTI, Mechanical with Impact
  • 170 °C
  • UL RTI, Mechanical without Impact
  • 180 °C
  • Flammability, UL94
  • V-0 @Thickness 0.250 mm
  • Flammability, UL94
  • 5VA @Thickness 1.21 mm
  • Oxygen Index
  • 50 %
  • Electrical Properties
  • Volume Resistivity
  • 3.00e+16 ohm-cm
  • Dielectric Constant
  • 3.7 @Frequency 1000 Hz
  • Dielectric Strength
  • 24.8 kV/mm @Thickness 1.60 mm
  • Dielectric Strength
  • 30.3 kV/mm @Thickness 1.60 mm
  • Dissipation Factor
  • 0.0015 @Frequency 1000 Hz
  • Dissipation Factor
  • 0.0053 @Frequency 2.45e+9 Hz
  • Arc Resistance
  • 60 - 120 sec
  • Comparative Tracking Index
  • 100 - 175 V
  • Hot Wire Ignition, HWI
  • 60 - 120 sec
  • High Amp Arc Ignition, HAI
  • 0.00 - 15 arcs
  • High Voltage Arc-Tracking Rate, HVTR
  • 80.0 - 150 mm/min
  • Descriptive Properties
  • NBS Smoke Density, Flaming, Ds 4 min
  • 1.6
