SABIC Innovative Plastics Lexan® 503 PC

Seller in Chicago price: $2419 per MT
Seller in Chittagong price: $2096 per MT
Seller in Shenzhen price: $1753 per MT

SABIC Innovative Plastics Lexan® 503 PC in Polymer, Thermoplastic, Polycarbonate (PC)

  • Physical Properties
  • Specific Gravity
  • 1.25 g/cc
  • Density
  • 1.245 g/cc
  • Water Absorption
  • 0.12 % @Time 86400 sec
  • Moisture Absorption at Equilibrium
  • 0.31 %
  • Linear Mold Shrinkage, Flow
  • 0.0020 - 0.0040 cm/cm @Thickness 3.20 mm
  • Mechanical Properties
  • Hardness, Rockwell M
  • 85
  • Hardness, Rockwell R
  • 124
  • Tensile Strength at Break
  • 55.0 MPa
  • Tensile Strength, Yield
  • 66.0 MPa
  • Elongation at Break
  • 15 %
  • Elongation at Yield
  • 8.0 %
  • Flexural Yield Strength
  • 103 MPa
  • Flexural Modulus
  • 3.44 GPa
  • Izod Impact, Notched
  • 1.06 J/cm
  • Izod Impact, Unnotched
  • 21.36 J/cm
  • Tensile Impact Strength
  • 157 kJ/m²
  • Dart Drop, Total Energy
  • 101 J
  • Taber Abrasion, mg/1000 Cycles
  • 11
  • Thermal Properties
  • CTE, linear, Parallel to Flow
  • 32.4 µm/m-°C @Temperature -40.0 - 95.0 °C
  • Specific Heat Capacity
  • 1.21 J/g-°C
  • Thermal Conductivity
  • 0.200 W/m-K
  • Deflection Temperature at 0.46 MPa (66 psi)
  • 146 °C @Thickness 6.40 mm
  • Deflection Temperature at 1.8 MPa (264 psi)
  • 142 °C @Thickness 6.40 mm
  • Vicat Softening Point
  • 154 °C
  • UL RTI, Electrical
  • 120 °C
  • UL RTI, Mechanical with Impact
  • 110 °C
  • UL RTI, Mechanical without Impact
  • 125 °C
  • Flammability, UL94
  • V-0 @Thickness 1.52 mm
  • Flammability, UL94
  • 5VA @Thickness 2.99 mm
  • Oxygen Index
  • 36 %
  • Electrical Properties
  • Volume Resistivity
  • >= 1.00e+17 ohm-cm
  • Dielectric Constant
  • 3.05 @Frequency 1.00e+6 Hz
  • Dielectric Constant
  • 3.1 @Frequency 50.0 - 60.0 Hz
  • Dielectric Strength
  • 17.7 kV/mm @Thickness 3.20 mm
  • Dissipation Factor
  • 0.00080 @Frequency 50.0 - 60.0 Hz
  • Dissipation Factor
  • 0.0075 @Frequency 1.00e+6 Hz
  • Arc Resistance
  • 0.00 - 60 sec
  • Comparative Tracking Index
  • 100 - 175 V
  • Hot Wire Ignition, HWI
  • 60 - 120 sec
  • High Amp Arc Ignition, HAI
  • 60 - 120 arcs
  • High Voltage Arc-Tracking Rate, HVTR
  • 80.0 - 150 mm/min
  • Descriptive Properties
  • Specific Volume
  • 0.8cm^3/g
  • UV-light, water exposure/immersion
  • F1

Alternative products

ShipsFor-Sale.com is a renowned company specializing in the sale of ships. With years of experience in the maritime industry, they have established themselves as a trusted platform for buyers and sellers worldwide. Offering an extensive range of vessels, including cargo ships, tankers, fishing boats, and luxury yachts, oil chemical tanker for sale. Their team of knowledgeable professionals provides expert guidance throughout the buying and selling process, ensuring smooth transactions and customer satisfaction. Whether you are a seasoned ship owner or a first-time buyer, ShipsFor-Sale.com offers a comprehensive selection of vessels and a seamless online experience, making them the go-to destination for ship sales.

Andrey Kutuzov

University of Córdoba (Spain), email: [email protected]

Work with plastics from August, 2015

3 prices for SABIC Innovative Plastics Lexan® 503 PC

Seller from Chicago – 2021-06-17:

Seller from Chicago work with company: Solvay, RTP Company, SABIC Innovative Plastics (GE Plastics), ALIMEX GmbH

Price: $2419 per MT

Seller from Chittagong – 2021-06-30:

Seller from Chittagong work with company: 3M, Solvay, SABIC Innovative Plastics (GE Plastics), ALIMEX GmbH

Price: $2096 per MT

Seller from Shenzhen – 2021-07-19:

Seller from Shenzhen work with company: Hexcel, Solvay, SABIC Innovative Plastics (GE Plastics), ALIMEX GmbH

Price: $1753 per MT
